Durkopp Adler 550-12-34

H-TYPE class 967 - PURE version of the flatbed machine for extreme applications without electrically and pneumatically operated functions

Field of application:

Universal sewing operations in the production of technical textiles, leather goods and upholstery.

Performance features:

• Max. stitch length 15mm
• Max. sewing speed 1,000 stitches/min (only with optional drive package)
• Max. alternating sewing foot stroke 12mm

Overview:

• Flat bed machine without electrically and pneumatically operated functions, equipped with XL barrel shuttle hook and manual sewing foot lift via pedal (optional with 'DEC eco' control and drive motor
• Excellent stitch pattern and constantly tight stitches, even when sewing with extremely thick threads up to max. Tkt. 5/3
• Up to 15mm long stitches for assemble and decorative seams
• The extremely high sewing foot lift up to 30mm facilitates the feeding and removal of bulky workpieces.
• The sewing foot stroke up to 12mm allows safe climbing over material plies with large differences in height.
• Large clearance (420mm wide and 225mm high)
• Optional equipment 'Heavy-duty applications': Improved transport, higher tractive force and uniform stitch tightening in very large material thicknesses due to triangular eccentric (max. 800 stitches/min. with drive package, stitch length max. 9mm; can only be ordered ex works, no external conversion possible)
