Durkopp Adler 838-270122-M

Twin needle post bed machine with driven roller presser and bottom feed

Field of application:

All kinds of leather, textile materials and sports shoes

Performance features:

• Max. needle gauge 3.2 mm
• Max. stitch length 10.0 mm
• Max. sewing speed 2,000 stitches/min.
• Max. sewing foot lift 12 mm
• Max. needle size 180 Nm

Overview:

• Highest precision on stitch locking even during sewing speed changes
• Pneumatic switchable second thread tension for optimized sewing results
• Low noise and vibration
• The powerful and effective feeding system with bottom feed and driven roller presser guarantees excellent material feed when processing different material thicknesses
• Electropneumatic presser foot lifting and backtacking enable the setting of high pressure on the foot for sewing heavy materials
• Large vertical hooks (26 mm bobbin)
• Lubricating system with central oil tank and oil pump
• Integrated built-in motor to save energy, easy main­tenance
• Switch button for setting a reduced stitch, e.g. at material borders
• Integrated electro-pneumatic elements
• Integrated keypad with an ergonomically arranged sensor key
